Carbon Steel Pipes
CARBON STEEL PIPES
Carbon Steel Pipes mainly used in the most critical engineering applications and also in certain applications in the automotive sector. In addition, some of the value-added Carbon Steel Pipe include steel for LPG cylinders, API grade, corrosion resistant steel, critical structural application steel, boiler quality, auto grades, precision tubes and medium/high carbon grades, among others.
GRADES OF CARBON STEEL PIPES & TUBES
API STD 5L Grade B, Carbon Steel Seamless Pipe
ASTM A 53 Grade B, Seamless, ASME SA 53 Grade B, Seamless
ASTM A106 Grade B, Seamless, ASME SA 106 Grade B, Seamless
ASTM A 53 Grade B, Welded
API 5 LX Grade X52, Seamless
API STD 5 L Grade B, Welded
API STD 5 LX Grade X 42, Welded
ASTM A 53 Grade B, Welded
API 5 L Grade B, Double Submerged Arc Welded (DSAW
API STD 5 LX Grade X 42, DSAW
A-120 / A53 Grade A Welded
Carbon Steel Pipes Specifications
Size Range: 1/2” NB to 36” NB
Thickness: SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules
Carbon Steel Pipe Specifications: ASTM A/ASME SA 53 Grade A, B | ASTM A/ASME SA 106 Grade A, B, C | ASTM A/ASME SA 333 Grade 1, 6 | API 5L – PSL 1 Gr. A, B, X42, X46, X52, X56, X60, X65, X70 | API 5L – PSL 2 Gr. B, X42, X46, X52, X56, X60, X65, X70
Applications: Oil Refineries, Petrochemicals, Power Generation (Nuclear/Thermal), Steel, Sugar, Boiler Equipments, Pressure Vessels and General Engineering Purposes
Carbon Steel Tubes/Tubing Specifications
Specifications: ASTM A/ASME SA 179 | ASTM A/ASME SA 192, ASTM A/ASME SA 210 Gr. 1, C | BS 3059 PART II GR. 360, 440, 620 | DIN 2391, ST 35, ST 37, ST 45, ST 52
Size Range: 1/2” to 6”, both OD and NB sizes available
Thickness: 50mm to 7.00mm, custom OD and thickness available on request
End Connections for Line Pipes: Plain, Bevel, Screwed, Threaded
Type: Seamless / ERW / Welded / Fabricated / CDW
Form: Round Pipes/Tubes, Square Pipes/Tubes, Rectangular Pipe/Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tubes
Length: Single Random, Double Random & Required Length, Custom Size – 12 Meter lengths
End: Plain End, Beveled End, Treaded
End Protection: Plastic Caps
Outside Coating: Black Painting, Anti-Corrosion Oil, Galvanised Finish, Finish as per customer Requirements
TYPES OF CARBON STEEL PIPE & TUBE
ASTM A53 Grade A Carbon Steel Pipe
ASTM A53 Grade B Carbon Steel Pipe
ASTM A106 Grade A Carbon Steel Pipe
ASTM A106 Grade B Carbon Steel Pipe
ASTM A106 Grade C Carbon Steel Pipe
ASTM A135 Carbon Steel Pipe
ASTM A139 Carbon Steel Pipe
ASTM A178 Carbon Steel Pipe
ASTM A179 Carbon Steel Tube/ Tubing
ASTM A210 Carbon Steel boiler tube
A333 Grade 3 Carbon Steel Pipe
A333 Grade 6 Carbon Steel Pipe
A334 Grade Carbon Steel Pipe
API 5L B, X42 to X80 Carbon Steel Pipe
ASTM A671 Carbon Steel pipe
ASTM A672 Carbon Steel pipe
EN Carbon Steel Seamless Pipe
JIS Carbon Steel Specification Pipe & Tube
