Electric Actuator

Valves

Standards : CE Marked, ISO5211, NEMA 4, NEMA 7, NEMA 9

Design : Reversing Type Capacitor Run Motor Design, Cut-Out, Compact Housing, Permanently Lubricated Gear Train, Manual Override, ISO5211 Mounting Dimensions, Female 'Star Drive' Output Shaft.

Duty Cycle : 50% to 100%

Cycle Time : 5 Seconds for 90 Degrees Rotation

Conduit Entry : 1/2" NPT

Torque Range : 17NM to 230NM

Supply Voltage : 12vDC, 24vDC, 115vAC, 240vAC

Modulating Position Control : Solid State 4-20mA or 0-10vDC Input Signals

Power Consumption : 0.5 Amps

Limit Switches : Two Single Pole Double Throw 15 Amp Rated

Material of Construction : Aluminium or Resin Housing With Stainless Steel Fasteners

Operation : 90 Degree, 180 Degree & Multi-Turn

Fail Safe Operation : Battery Back Up

Centre Off Operation : Facilitates Off or 90 Degree Positioning of Diverter Valves

Heater & Thermostat : Internally Wired for Low Temperature or High Humidity Applications

Mechanical Brake : Eliminates Hydrodynamic Movement in Butterfly Valve Applications

Position Feedback : 0-1000 Ohm Potentiometer
